Field Bendable Linear

Kurba Small

Field Bendable 24V System

16-180 lm/ft, 1.4-2.8 W/ft

52.5-590.4 lm/m, 4.6-9.2 W/m

IP67
Overview
Specifications
Metric Units

Kurba Small is a direct view, small profile, energy efficient and flexible LED strip suitable for outdoor wet locations capable of horizontal/side bends and vertical/top bends with a 2in bending radius. The silicone material offers excellent heat, weather, UV, and solvent resistance and is self cleaning which repels dust and dirt accumulation.

  • CCT: 2200K, 2400K, 2600K, 2700K, 3000K, 3500K, 4000K, 4200K
  • CRI: 90+
  • Type: Bendable
  • Output Per: 52.5 lm/m, 16 lm/ft, 534.6 lm/m, 163 lm/ft, 590.4 lm/m, 180 lm/ft, 278.8 lm/m, 85 lm/ft, 314.9 lm/m 96 lm/ft
  • Mounting: Recessed, Surface
  • Bend Type: Horizontal, Vertical
  • Input Voltage: Low Voltage
  • Color: Static White
  • Optics: Black Lens
  • Wattage Per: 4.6 W/m, 1.4 W/ft, 9.2 W/m 2.8 W/ft
  • Rating: IP67
  • Lens Aperture: 9.9 mm 0.39 inch
  • Size: 9.9 mm, 0.39 in, 10 mm
  • Height: 9.906 mm 0.39 in
  • Lens: Black Lens, Silicone Frosted
  • Operating Temperature: -40°C to 55°C, -40°C to 65°C, -40-65 C -40°F to 149°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Manufacturing Details: Shipped from UK
  • Warranty: 5 Years
  • Finishes: Black silicon, White silicon
  • Product Number: KBS
Learn more
Specsheets
Install Guides
Cross Reference Guide
DWG CAD
IES Files
North America
Kurba Small V H Static White Specsheet
2.25 MB
PDF
UK, Europe, MEA, Asia
Kurba Small W Static White EMEA
1.3 MB
PDF
Kurba-Install-Guide
2.14 MB
PDF
Kurba Cross Reference
581.27 KB
PDF
Kurba Small Horizontal 2D Dimensioning
390.74 KB
DWG
Kurba Small IES EMEA
13.18 KB
ZIP
KBS-W-HB-48-44SO-30K-R80-SF-NA-WH.ies
3.01 KB
IES
KBS-W-VB-48-51SO-26K-R80-BL-NA-BK.ies
2.83 KB
IES
KBS-W-HB-48-44HO-30K-R80-SF-NA-WH.ies
3.1 KB
IES
KBS-W-VB-48-44SO-30K-R80-SF-NA-WH.ies
3.04 KB
IES
KBS-W-VB-48-44SO-30K-R80-BL-NA-BK.ies
2.89 KB
IES
KBS-W-VB-48-44HO-30K-R80-SF-NA-WH.ies
3.12 KB
IES
KBS-W-HB-48-51SO-26K-R80-BL-NA-BK.ies
2.78 KB
IES
KBS-W-HB-48-44HO-30K-R90-SF-NA-WH.ies
3.08 KB
IES
KBS-W-VB-48-44HO-30K-R90-SF-NA-WH.ies
3.11 KB
IES
KBS-W-VB-48-44SO-30K-R90-SF-NA-WH.ies
2.97 KB
IES
KBS-W-HB-48-44SO-30K-R90-SF-NA-WH.ies
2.95 KB
IES
