Kilo Graze-Wash – Dynamic Color

Surface Mount Linear 24V System

Warm DimTunable WhitePixelRGB/RGBW
Overview
Specifications
  • 24VDC Class 2 fixtures made to order up to 116”. Fixtures can be linked up to 32’ depending on output
  • Suitable for wall wash applications
  • Approved for closet/storage space installation per NEC 410.16(A) (3) and 410.16(C)(5) on outputs 5.7 W/ft or less
  • Class two listed for damp locations.
  • Dot free even illumination with wash lens
  • Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors.
  • Average Life (L70): 50,000hrs
  • Tunable White allows individual control of CCT and output, can be paired with Vintage Dim power supply for warm dim effect
  • Warm Dim follows the incandescent dimming curve and is compatible with MLV, ELV, and Incandescent dimmers.
  • RGB offers balanced output across the color gamut and a true white with RGBW
  • Smart Pixel allows for infinite color combinations with cascading and chasing effects
  • 7 year warranty
  • CCT: 19K - 27K, 19K - 35K, 27K - 65K, RGB30K
  • CRI: 98
  • Output / ft: 71 lm/ft, 89 lm/ft, 90 lm/ft, 108 lm/ft, 147 lm/ft, 178 lm/ft, 214 lm/ft
  • Mounting: Surface, Wall Mount
  • Type: Linear Fixture
  • Input Voltage: Low Voltage
  • Color: Warm Dim, Tunable White, RGB/RGBW, Pixel
  • Wattage / ft: 4.0 W/ft, 4.5 W/ft, 4.6 W/ft, 5.4 W/ft, 5.6 W/ft, 5.7 W/ft
  • Lens Aperture: 1.22 inch
  • Size: 1.38 in
  • Height: 1.38 in
  • Lens: Clear, Frosted
  • Operating Temperature: -5°F to 125°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Made In: Made in America
  • Warranty: 7 years
  • Product Number: KGW
