Kendo XL Surface Wet – Dynamic Color

Surface Mount Wet Location Linear 24V System

Warm DimTunable WhitePixelRGB/RGBWIP68
Overview
Specifications
  • 24VDC Class 2 and IP68 rated for wet locations, fixtures made to order up to 144”. Fixtures can be linked up to 30’ depending on output
  • Suitable for surface mount, direct view, outdoor, wet, and accent lighting applications
  • Dot free even illumination with frosted lens
  • Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors.
  • Average Life (L70): 50,000hrs
  • 3 year warranty
  • Warm Dim follows the incandescent dimming curve and is compatible with MLV, ELV, and Incandescent dimmers.
  • Tunable White allows individual control of CCT and output, can be paired with Vintage Dim power supply for warm dim effect
  • RGB offers balanced output across the color gamut and a true white with RGBW
  • Smart Pixel allows for infinite color combinations with cascading and chasing effects
  • CCT: 22K - 32K, 22K - 46K, RGB40K
  • CRI: 98
  • Output / ft: 126 lm/ft, 157 lm/ft, 158 lm/ft, 191 lm/ft, 231 lm/ft, 260 lm/ft, 262 lm/ft, 508 lm/ft
  • Mounting: Surface
  • Type: Linear Fixture
  • Input Voltage: Low Voltage
  • Color: Pixel, RGB/RGBW, Tunable White, Warm Dim
  • Wattage / ft: 10.1 W/ft, 4.0 W/ft, 4.5 W/ft, 5.7 W/ft, 7.3 W/ft, 7.6 W/ft, 8.3 W/ft
  • Rating: IP68
  • Lens Aperture: 0.62 inch
  • Size: 0.83 in
  • Height: 0.51 in
  • Lens: Clear, Frosted
  • Operating Temperature: -15°F to 125°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Made In: Made in America
  • Warranty: 3 Years
  • Product Number: KXLW
