Teava Wall – Static White

Wall mounted display lighting

Damp
Overview
Specifications
  • Extruded aluminum display and wall light system.
  • 24VDC Class 2 fixtures made to order up to 232”
  • Class 2 listed for damp locations
  • Approved for closet/storage space installation per NEC 410.16(A) (3) and 410.16(C)(5) on outputs 5.7W/ft or less
  • Dot free even illumination with frosted lens
  • Average Life (L70): 50,000hrs
  • High Color Quality options offer premium quality and vibrant colors with R9 values up to 97
  • High Efficacy options offer best in class output and efficacy with over 540 lm/ft and up to 76 lm/W
  • Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors
  • 7 Year warranty
  • CCT: 1900K, 2200K, 2400K, 2500K, 2700K, 3000K, 3500K, 4000K, 4100K
  • CRI: 98
  • Output / ft: 144 lm/ft, 148 lm/ft, 200 lm/ft, 240 lm/ft, 266 lm/ft, 292 lm/ft, 427 lm/ft, 541 lm/ft
  • Mounting: Wall Mount
  • Input Voltage: Low Voltage
  • Wattage / ft: 1.9 W/ft, 2.8 W/ft, 3.5 W/ft, 4.8 W/ft, 6 W/ft, 6.5 W/ft, 7.5 W/ft
  • Lens Aperture: 0.50 inch
  • Operating Temperature: -5°F to 125°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Made In: Made in America
  • Warranty: 7 years
  • Color: Static White
  • Type: Linear Fixture
  • Rating: Damp
  • Size: 0.95 in
  • Height: 0.95 in
  • Lens: Clear, Frosted
  • Product Number: TEA
