Runda Closet Rod - Static White - Luminii

Runda Closet Rod – Static White

Runda Closet Rod - Static White

Overview

Specifications

24VDC Class 2 fixtures made to order up to 116”.
Suitable for illuminating clothing and other hanging items.
Approved for closet/storage space installation per NEC 410.16(A) (3) and 410.16(C)(5) on outputs 5.2 W/ft or less
Class 2 listed for damp locations
Dot free even illumination with frosted lens
1/2” of space from LED is available on either end of the extrusion for field cutting.
High Color Quality options offer premium quality and vibrant colors with R9 values up to 97 Class 2 listed for damp locations
High Efficacy options offer best in class output and efficacy with over 640 lm/ft and up to 91 lm/W
Average Life (L70): 50,000hrs
7 Year warranty

CCT: 1900K, 2200K, 2400K, 2500K, 2700K, 3000K, 3500K, 4000K, 4100K
CRI: 98
Output / ft: 172 lm/ft, 176 lm/ft, 238 lm/ft, 287 lm/ft, 318 lm/ft
Mounting: Closet
Input Voltage: Low Voltage
Wattage / ft: 1.9 W/ft, 2.8 W/ft, 3.5 W/ft, 4.8 W/ft
Lens Aperture: 1.50 inch
Operating Temperature: -5°F to 95°F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 7 years
Color: Static White
Type: Linear Fixture
Size: 1.50 in
Height: 1.50 in
Lens: Clear, Frosted
Product Number: RCR

JA8/Title 24

RoHS/Reach

Runda Closet Rod Static White Specsheet

4.11 MB

PDF

Runda Closet Rod Install Guide

410.01 KB

PDF

Luminii Cross Reference Luminii Optic Arts

PDF

RCR-48-30K-72HO-C.ies

9.62 KB

IES

RCR-48-30K-72HO-F.ies

3.68 KB

IES
