mCove Dynamic Color

mCove – Dynamic Color

Surface Mount Linear 24V Cove System

Overview

Specifications

24VDC Class 2 fixtures made to order up to 144”. Fixtures can be linked up to 32’ depending on output
Suitable for wall mount applications
Available with long throw and tall throw reflectors
Class 2 listed for damp locations
Dot free even illumination achievable Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors.
Tunable White allows individual control of CCT and output, can be paired with Vintage Dim power supply for warm dim effect
Warm Dim follows the incandescent dimming curve and is compatible with MLV, ELV, and Incandescent dimmers.
RGB offers balanced output across the color gamut and a true white with RGBW
Smart Pixel allows for infinite color combinations with cascading and chasing effects
Average Life (L70): 50,000hrs
7 Year warranty

CCT: 19K - 27K, 19K - 35K, 27K - 65K, RGB30K
CRI: 95+
Output / ft: 153 lm/ft, 190 lm/ft, 192 lm/ft, 232 lm/ft, 280 lm/ft, 315 lm/ft, 318 lm/ft, 382 lm/ft, 459 lm/ft
Mounting: Wall Mount
Input Voltage: Low Voltage
Wattage / ft: 4 W/ft, 4.5 W/ft, 4.6 W/ft, 5.4 W/ft, 5.6 W/ft, 5.7 W/ft, 7.6 W/ft, 8.3 W/ft
Lens Aperture: 2.60 inch
Operating Temperature: -5°F to 125°F
Made In: Made in America
Warranty: 7 years
Color: Pixel, RGB/RGBW, Tunable White, Warm Dim
Type: Linear Fixture
Rating: Damp
Size: 2.60 in
Height: 1.50 in
Lens: Clear
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Product Number: M

Premium Grade Surface Mount Cove Channel

Surface Mount Linear 24V Cove System
