Kurat – Static White

Suspended Linear 24V System

Overview

Specifications

24VDC Class 2 fixtures made to order up to 116”.
Class 2 listed for damp locations
Dot free even illumination
Available with a remote power supply or an integral power supply option mounted in the canopy.
Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors
High Color Quality options offer premium quality and vibrant colors with R9 values up to 97
High Efficacy option offers highest output and efficacy, with over 490 lm/ft and up to 69 lm/W.
Average Life (L70): 50,000hrs
7 year warranty

CCT: 1900K, 2200K, 2400K, 2500K, 2700K, 3000K, 3500K, 4000K, 4100K
CRI: 98
Output / ft: 131 lm/ft, 135 lm/ft, 182 lm/ft, 219 lm/ft, 243 lm/ft, 266 lm/ft, 389 lm/ft, 492 lm/ft
Mounting: Suspended
Input Voltage: Line Voltage, Low Voltage
Wattage / ft: 1.9 W/ft, 2.8 W/ft, 3.5 W/ft, 4.8 W/ft, 6 W/ft, 6.5 W/ft, 7.5 W/ft
Lens Aperture: 0.77 inch
Operating Temperature: -5°F to 125°F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 7 years
Color: Static White
Type: Linear Fixture
Rating: Damp
Size: 0.77 in
Height: 0.49 in
Lens: Frosted
Product Number: KUR
