Kilo Surface - Dynamic Color

Kilo Surface – Dynamic Color

Surface Mount Linear 24V System

Overview

Specifications

24VDC Class 2 fixtures made to order up to 144”. Fixtures can be linked up to 16’ depending on output
Approved for closet/storage space installation per NEC 410.16(A) (3) and 410.16(C)(5) on outputs 5.7 W/ft or less
Dot free even illumination with frosted lens
Class two listed for damp locations
Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors
Average Life (L70): 50,000hrs
7 year warranty
Tunable White allows individual control of CCT and output, can be paired with Vintage Dim power supply for warm dim effect
Warm Dim follows the incandescent dimming curve and is compatible with MLV, ELV, and Incandescent dimmers.
RGB offers balanced output across the color gamut and a true white with RGBW
Smart Pixel allows for infinite color combinations with cascading and chasing effects

CCT: 19K - 27K, 19K - 35K, 27K - 65K, RGB30K
CRI: 98
Output / ft: 253 lm/ft, 315 lm/ft, 318 lm/ft, 384 lm/ft, 463 lm/ft, 522 lm/ft, 526 lm/ft, 633 lm/ft, 760 lm/ft
Mounting: Surface
Type: Linear Fixture
Input Voltage: Low Voltage
Color: Pixel, RGB/RGBW, Tunable White, Warm Dim
Wattage / ft: 10.8 W/ft, 11.2 W/ft, 11.4 W/ft, 15.2 W/ft, 16.6 W/ft, 8.0 W/ft, 9.0 W/ft, 9.2 W/ft
Rating: Damp
Lens Aperture: 1.05 inch
Size: 1.50 in
Height: 1.50 in
Lens: Clear, Frosted
Operating Temperature: -5°F to 125°F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 7 years
Product Number: K
