Kendo 45M Wet - Dynamic Color - Luminii

Kendo 45M Wet – Dynamic Color

Surface Mount Wet Location Linear 24V System

Warm Dim

Tunable White

RGB/RGBW

Overview

Specifications

24VDC Class 2 and IP68 rated for wet locations, fixtures made to order up to 128”.Fixtures can be linked up to 30’ depending on output.
Suitable for undercabinet, millwork recessed, and surface mount applications
Dot free even illumination with frosted lens
Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors
WD68 Warm Dim follows the incandescent dimming curve and is compatible with MLV, ELV, and Incandescent dimmers.
DW52 Dynamic White allows individual control of CCT and output
RGB options offer balanced output across the color gamut and a true white with RGBW
Smart Pixel offerings allow for infinite color combinations with cascading and chasing effects.
3 year warranty

CCT: 2200K, 3200K, 3500K, 4600K
CRI: 98
Output / ft: 101 lm/ft, 126 lm/ft, 127 lm/ft, 154 lm/ft, 186 lm/ft, 209 lm/ft, 211 lm/ft, 253 lm/ft, 304 lm/ft
Mounting: Surface
Input Voltage: Line Voltage
Color: Pixel, RGB/RGBW, Static White, Tunable White, Warm Dim
Wattage / ft: 4.0 W/ft, 4.5 W/ft, 4.6 W/ft, 5.4 W/ft, 5.6 W/ft, 5.7 W/ft, 7.6 W/ft, 8.3 W/ft
Lens Aperture: - 0.5 inch
Operating Temperature: 104 F, 113 F, 122 F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 7 years
Product Number: K45MW

JA8/Title 24

RoHS/Reach

Kendo 45M Wet Dynamic Color Spec
