Kilo Surface - Static White - Luminii

Kilo Surface – Static White

Surface Mount Linear 24V System

Damp

Overview

Specifications

24VDC Class 2 fixtures made to order up to 144 inches. Fixtures can be linked up to 16 feet depending on output
Suitable for undercabinet, millwork recessed and surface mount applications
Approved for closet/storage space installation per NEC 410.16(A)(3) and 410.16(C)(5)
Dot free even illumination achievable in with frosted lens
Vibrant colors with R9 values up to 98
Single micro binned LEDs +/- 30 CCT
Dims with minimal color shift Class 2 listed for damp locations
Proprietary strong bond solder method handles up to 50lbs of torque on wire leads and connectors

CCT: 1900K, 2200K, 2400K, 2500K, 2700K, 3000K, 3500K, 4000K, 4100K
CRI: 98
Output / ft: 1179 lm/ft, 1492 lm/ft, 397 lm/ft, 408 lm/ft, 550 lm/ft, 663 lm/ft, 735 lm/ft, 806 lm/ft
Mounting: Surface
Input Voltage: Line Voltage
Color: Static White
Wattage / ft: 12 W/ft, 13 W/ft, 15 W/ft, 3.8 W/ft, 5.6 W/ft, 7.0 W/ft, 9.6 W/ft
Lens Aperture: 1.05 inch
Operating Temperature: 122 F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 7 years
Product Number: K

JA8/Title 24

RoHS/Reach

Kilo Surface System Static White Spec

9.73 MB

PDF

Kilo Instructions

560.67 KB

PDF

KILO - FROSTED - LL72-VHO-30K_IES.IES

3.48 KB

IES

KILO - CLEAR - LL72-VHO-30K_IES.IES

3.5 KB

IES

Lighting Luminii Kilo Surface (1).rfa

532 KB

RFA

LuMinii Cross Reference LuMinii Optic Arts

2.6 MB

PDF

Kilo 2D Dimensions.dwg

670.86 KB

DWG
