Wall Plus – Dynamic Color

Recessed Linear 24V System

PixelRGB/RGBWDamp
Overview
Specifications
  • 24VDC Class 2 fixtures made to order up to 120”.
  • Approved for closet/storage space installation per NEC 410.16(A) (3) and 410.16(C)(5) on outputs 5.7 W/ft or less
  • Class two listed for damp locations.
  • Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors.
  • RGB offers balanced output across the color gamut and a true white with RGBW
  • Smart Pixel allows for infinite color combinations with cascading and chasing effects
  • Average Life (L70): 50,000hrs
  • 7 year warranty
  • CRI: 95+
  • CCT: RGB30K
  • Output / ft: 109 lm/ft, 136 lm/ft, 137 lm/ft, 166 lm/ft, 200 lm/ft, 227 lm/ft
  • Mounting: Recessed
  • Input Voltage: Low Voltage
  • Wattage / ft: 4 W/ft, 4.5 W/ft, 5.7 W/ft, 7.6 W/ft, 8.3 W/ft
  • Lens Aperture: 0.50 inch
  • Operating Temperature: -5°F to 125°F
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Made In: Made in America
  • Warranty: 7 years
  • Color: RGB/RGBW, Pixel
  • Type: Linear Fixture
  • Rating: Damp
  • Size: 2.43 in
  • Height: 3.74 in
  • Lens: Frosted
  • Product Number: WP
