Kendo XL Recessed - Dynamic Color

Kendo XL Recessed – Dynamic Color

Recessed Linear 24V System

Overview

Specifications

24VDC Class 2 fixtures made to order up to 144 inches. Fixtures can be linked up to 30 feet depending on output
Suitable for millwork, recessed, architectural reveals, accent light, and surface mount applications
Approved for closet/storage space installation per NEC 410.16(A)(3) and 410.16(C)(5)
Dot free even illumination with frosted lens
Vibrant colors with R9 values up to 98
Single micro binned LEDs +/- 30 CCT
Dims with minimal color shift
Class 2 listed for damp locations
Proprietary strong bond solder method handles up to 50lbs of torque on wire leads and connectors

CCT: 1900K, 2700K, 2900K, 3500K, 4400K, 6500K
CRI: 98
Output / ft: 133 lm/ft, 165 lm/ft, 167 lm/ft, 202 lm/ft, 243 lm/ft, 274 lm/ft, 276 lm/ft, 535 lm/ft
Mounting: Recessed
Input Voltage: Line Voltage
Color: Pixel, RGB/RGBW, Tunable White, Warm Dim
Wattage / ft: 4.0 W/ft, 4.5 W/ft, 5.4 W/ft, 5.7 W/ft, 7.3 W/ft, 7.6 W/ft, 8.3 W/ft
Lens Aperture: 0.62 inch
Operating Temperature: 122 F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 5 Years
Product Number: KRXL
